MIL-PRF-46197A
TABLE I.
Laminate physical and mechanical properties
.
Property
Requirement
Test Method
Paragraph
Resin content, % by wt
32 ± 3
4.6.1
Density, g/cc
1.84 - 1.98
4.6.2
Tensile modulus, (min avg)
2.3 Msi (15859 Mpa)
4.6.3
Tensile strength, (min avg)
43 Ksi (296 Mpa)
4.6.3
Flexural modulus, (min avg)
2.5 Msi (17238 Mpa)
4.6.4
Flexural strength, (min avg)
32 Ksi (221 Mpa)
4.6.4
Compressive strength, (min avg)
20 Ksi (138 Mpa)
4.6.5
Short beam shear strength, (min avg)
2.5 Ksi (17.2 Mpa)
4.6.6
Glass transition temp, °F (°C) min
295°F (146°C)
4.6.7
Flammability
Pass
4.6.8
9
